突威格TORWEGGE

德TORWEGGE弹性聚氨酯轮EPUK-125-40-50-K15-VA

陈华丽 QQ：2351635597   手机：18519260275 电话：010-64714988-172 传真：010-84786709-667 邮件：sales65@handelsen.cn

TORWEGGE弹性聚氨酯轮蓝紫色滚珠轴承 VA 80mm

EPUK-080-35-40-K12-VA

TORWEGGE弹性聚氨酯轮蓝紫色滚珠轴承 VA 100mm

EPUK-100-35-40-K12-VA

TORWEGGE弹性聚氨酯轮蓝紫色滚珠轴承 VA 125mm

EPUK-125-40-50-K15-VA

TORWEGGE弹性聚氨酯轮蓝紫色滚珠轴承 VA 160mm

EPUK-160-45-60-K20-VA

TORWEGGE弹性聚氨酯轮蓝紫色滚珠轴承 VA 200mm

EPUK-200-50-60-K20-VA

TORWEGGE弹性聚氨酯轮蓝紫色滚珠轴承 VA 250mm

EPUK-250-60-75-K25-VA

TORWEGGE弹性聚氨酯轮蓝紫色滚珠轴承 VA 250mm

轮体由聚酰胺制成，带不锈钢滚珠轴承

胎面由弹性聚氨酯制成，大约 80° Shore A，

带圆形侧面。

该车轮系列的特点是运行安静

、滚动阻力小。

车轮的低磨损特性不会在地板上留下任何痕迹。

弹性胎面确保更高的驾驶舒适性。

技术规格

轴孔Ø (mm)25

EAN代码4042974269171

轮辋颜色白色的

轮圈材质聚酰胺

体重（公斤）2,345

滚珠轴承密封2RS

滚珠轴承名称6205-2RS-VA

胎面直径 (mm)250

胎面类型加冕

胎面颜色蓝紫色

胎面材料弹性聚氨酯

轮毂直径 (mm)85

轮毂长度（毫米）75

砂轮直径 (mm)250

轮宽（毫米）60

车轮轴承滚珠轴承 VA

轮型车轮

负载能力（公斤）500

高耐温性 (°)80

低耐温性 (°)-20

货号型号车轮直径轮宽承载量

0014362

EPUK-080-35-40-K12-VA80mm35mm150公斤

0014363

EPUK-100-35-40-K12-VA100mm35mm180公斤

0014364

EPUK-125-40-50-K15-VA125mm40mm200公斤

0014366

EPUK-160-45-60-K20-VA160mm45mm300公斤

0031282

EPUK-160-45-60-K20-VA-RAL7045160mm45mm300公斤

0014367

EPUK-200-50-60-K20-VA200mm50mm450公斤

0030690

EPUK-200-50-60-K20-VA-RAL7045200mm50mm450公斤

品牌	货号	型号
AQ	D72	Ultrasound Controller D72 Rev.E
AQ	FCP10-25	FCP10-25 Air Sensor PP 10mm TC25  certificate included
AQ	FCP14-25	FCP14-25 Air Sensor PP 14mm TC25  certificate included
AQ	FCP22-50	FCP22-50 Air Sensor PP 22mm TC50  certificate included
AQ	FCP4-25	FCP4-25 Air Sensor PP 4mm TC25  certificate included
AQ	FCP6-25	FCP6-25 Air Sensor PP 6mm TC25  certificate included
AQ	SAC10-25 2.Gen	SAC10-25  without cable, Air Sensor 316L 10mm TC25 con Material 3.1B and Ra<0.375um certificate included
AQ	SAC16-25 2.Gen	SAC16-25 without cable, Air Sensor 316L 16mm TC25 con Material 3.1B and Ra<0.375um certificate included
AQ	SAC22-50 2.Gen	SAC22-50  without cable, Air Sensor 316L 22mm TC50 con Material 3.1B and Ra<0.375um certificate included
AQ	SAC22-50-EX 2.Gen	SAC22-50-EX  without cable, Air Sensor 316L 22mm TC50 Ex SP17ATEX3654X - II 1/2G Ex ib IIB T4 Ga/Gb Material 3.1B and Ra<0.375um certificate included
AQ	SAC35-50 2.Gen	SAC35-50 without cable, Air Sensor 316L 35mm TC50 con 6,00 pcs 2 332,00 30,0 9 794,40 Material 3.1B and Ra<0.375um certificate included
AQ	SAC35-50-EX 2.Gen	SAC35-50-EX  without cable, Air Sensor 316L 35mm TC50 Ex SP17ATEX3654X - II 1/2G Ex ib IIB T4 Ga/Gb Material 3.1B and Ra<0.375um certificate included
AQ	SAC4.5-25 2.Gen	SAC4.5-25 without cable, Air Sensor 316L 16mm TC25 con Material 3.1B and Ra<0.375um certificate included
AQ	SAC6-25 2.Gen	SAC6-25 without cable, Air Sensor 316L 16mm TC25 con Material 3.1B and Ra<0.375um certificate included
AQ	WG-Cable-7M Ex, 2.Gen.	Blue Cable 7Meter, angled conn, los, for SAC
AQ	WG-Cable-7M, 2.Gen	Grey Cable 7Meter, angled connect, los, for SAC
AQ	SAC8-25 2.Gen	SAC8-25 without cable, Air Sensor 316L 7.75mm TC25 Material 3.1B and Ra<0.375um certificate included
